H-bridge gantry structure with high-speed motion and ±0.2mm or ±0.2% positional accuracy
Direct drive dual extrusion print head with auto-nozzle lifting system
Temperature-controlled build chamber up to 70°C, heated bed up to 120°C
Print core temperature up to 340°C supporting high-performance engineering materials
Automated material handling system with 6 bays and NFC recognition
Built-in accelerometer and closed-loop feed control
>95% print success rate (tested with UltiMaker materials)
Print process reporting with real-time deviation monitoring
Modular design for quick maintenance and part replacement
Integrated HEPA filtration removing 95% of ultrafine particles

Print Technology: FDM
Build Volume: Single 330×240×300mm, Dual 330×240×300mm
Filament Diameter: 2.85mm
Dimensions: 695×605×1287mm
Weight: 120kg
Max Nozzle Temp: 340°C (HT print core)
Max Bed Temp: 120°C
Chamber Temp: Up to 70°C
Dimensional Accuracy: ±0.2mm±0.2% feature nominal length
XYZ Resolution: 6.25, 7.8, 2.5 micron
Layer Height: Min 20 micron
Material Compatibility: 14+ UltiMaker materials, 250+ third-party materials
